10GBASE-BX BiDi SFP+ 1270nm-TX/1330nm-RX 60km DOM Simplex LC/UPC SMF Optical Transceiver Module
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
The 10GBASE-BX BiDi SFP+ is a 1270nm-TX / 1330nm-RX optical transceiver designed for 10Gbps high-speed data transmission over single-mode fiber (SMF). It features a Simplex LC/UPC connector and supports a maximum transmission distance of 60km with DOM (Digital Optical Monitoring) functionality. This module is specifically paired with the BiDi SFP+ 1330nm-TX / 1270nm-RX transceiver for efficient bidirectional communication over a single fiber strand. Ideal for long-haul data center interconnections, enterprise networks, and telecom applications, it provides a reliable and cost-effective networking solution.
| Brand | WHGEARLINK |
|---|---|
| Description | SFP+ 10G Tx1270/Rx1330 60Km LC |
| Data Rate | 10G |
| Package | SFP+ |
| Wavelength (nm) | Tx1270nm/Rx1330nm |
| Reach | 60km |
| Connector | LC |
| Operating Voltage | 3.3V |
| TX output （dBm） | 0~5 |
| RX Sensitivity （dBm） | -20 |
| Power Consumption（W） | <1W |
| Operating Temperature | 0 to 70°C (32 to 158°F) |
| Cable Type | SMF |
| Warranty | 3 Years |
Be the first to review “10GBASE-BX BiDi SFP+ 1270nm-TX/1330nm-RX 60km DOM Simplex LC/UPC SMF Optical Transceiver Module”
Supports up to 10.7Gbps bit rates
Hot-pluggable SFP+ footprint
1270nm DFB laser and APD photodiode, Up to 60km for SMF transmission
Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle
Compatible with RoHS
Single +3.3V power supply
Real Time Digital Diagnostic Monitoring
Operating case temperature:
Standard: 0 to +70°C
Industrial: -40 to +85°C
