10GBASE-BX BiDi SFP+ 1550nm-TX/1490nm-RX 80km DOM Simplex LC/UPC SMF Optical Transceiver Module
Discover the 10GBASE‑BX BiDi SFP+ bidirectional transceiver for long-distance, bidirectional fiber links. High-performance 10G BIDI SFP+ modules, optimized for reliable 80 km 10G data transfer.
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
The 10GBASE-BX BiDi SFP+ is a 1550nm-TX / 1490nm-RX optical transceiver designed for 10Gbps high-speed data transmission over single-mode fiber (SMF). It features a Simplex LC/UPC connector and supports a maximum transmission distance of 80km with DOM (Digital Optical Monitoring) functionality. This module is specifically paired with the BiDi SFP+ 1490nm-TX / 1550nm-RX transceiver for efficient bidirectional communication over a single fiber strand. Ideal for long-distance telecom networks, metro networks, and data center interconnections, it offers reliable and cost-effective optical connectivity.
| Brand | WHGEARLINK |
|---|---|
| Description | SFP+ 10G Tx1550/Rx1490 80Km LC |
| Data Rate | 10G |
| Package | SFP+ |
| Wavelength (nm) | Tx1550nm/Rx1490nm |
| Reach | 80km |
| Connector | LC |
| Operating Voltage | 3.3V |
| TX output （dBm） | 0~4 |
| RX Sensitivity （dBm） | -23 |
| Power Consumption（W） | <1.5W |
| Operating Temperature | 0 to 70°C (32 to 158°F) |
| Cable Type | SMF |
| Warranty | 3 Years |
